Conveyor Rubber Sealing System/Conveyor Skirt Board/ Skirting Sheets

Conveyor Rubber Sealing System/Conveyor Skirt Board/ Skirting Sheets

PU plate refers to PU sandwich plate made of PU or formed by compounding PU and color steel plates.

Send Inquiry
Product Introduction

In order to seek greater development, our company does not focus on the existing 7 Crystal Water Zinc Borate, Polyurethane Rubber Parts, PTMEG Type MDI System Polyurethane Elastomer market, but actively explore new markets. We win the market by reputation, win trust by loyalty, and work hand in hand with our customers to seek common development and achieve mutual benefit and win-win. The current market competition has entered the era of brand competition, and consumer consumption has also entered the era of brand consumption.

PU Sheet

PU plate refers to PU sandwich plate made of PU or formed by compounding PU and color steel plates. It features diversified chemical structure, easily adjusted viscosity, excellent processing technology, easy input into industrial production, convenient use, quick curing and so on. PU plate is mainly applied to industrial and civil building external insulation systems. Currently, PU plate has become a product system in which PU is used most widely.


Characteristics and properties of Polyurethane Sheet

(1) Good wear resistance

(2) Wide range of hardness

(3) Strong mechanical strength

(4) Good oil resistance

(5) Good water resistance

(6) Good heat resistance and oxidation resistance

(7) Good low temperature resistance

(8) Strong vibration absorption performance

(9) Good electrical insulation performance


Application as below

Industry

Applications

Automotive

Grommets, bearings, bushes, flexible couplings.

Building and Construction

Mould for concrete, gate seals, concrete pump parts, waterproofing.

Coated fabrics

Conveyor belts, fuel storage tanks, power transmission belts.

Electrical

Encapsulation, insulation, potting, cable joining.

Engineered Components

Gears, sprockets, wire guides, rail draft gear, stripper plates, press brake pads, textile yarn guides, cutting boards, business machine belts, couplings.

Food

Chute lining, grain buckets.

Mining

Bucket liners, conveyor rollers, scraper blades, floatation cell impellers, pump linings, grading screens, lined pipes, cross-over pads.

oil, Chemical and Marine

Bushings, bearings, hydrocyclones, buoys, pipeline pigs and scrapers, fenders, valve seats.

Rollers

Board rollers, nip rollers, metal forming, printing, conveyor, can coating, paper mill.

Seals and Gaskets

Pneumatic and oil seals, diaphragms.

Footwear

Shoe soles, bottom moulding diaphragms, wear plates, energy absorbing insoles.

Wheel and Tyre

Fork-lift tyre, heavy duty castor wheels, escalator wheels, roller skate wheels, roller blade wheels.


Physical Properties and performance

TYPE

Polyether

HARDNESS

70shore A

80 shore A

90 shore A

70 shore A

80 shore A

90 shore A

density

1.13g/cm³

1.12g/cm³

1.13g/cm³

1.24g/cm³

1.26g/cm³

1.27g/cm³

Tensile strength

6.2MPa

18.3MPa

28.8MPa

24.5MPa

45MPa

48MPa

Tear strength

37KN/M

61 KN/M

78 KN/M

58 KN/M

73 KN/M

89 KN/M

elongation

602%

510%

422%

448%

578%

608%

100% for the tensile

2.3MPa

4.2MPa

6.9MPa

2.3MPa

5.2MPa

9.3MPa

300% for the tensile

3MPa

7.6MPa

13.8MPa

4.7MPa

9.9MPa

16.9MPa

DIN abrasion

240 mm³

121 mm³

127 mm³

90 mm³

47 mm³

56mm³

elasticity

28%

26%

28%

23%

35%

30%

Constant pressure

26%(25℃×25h×25%)

12%(25℃×25h×25%)

13%(25℃×25h×25%)

1%(25℃×25h×25%)

18%(25℃×25h×25%)

13%(25℃×25h×25%)

Note:DIN abrasion, gaseous tension, elasticity all for 8mm thickness sheet.


Standard size list

TYPE：PPG type / Polyester type

HARDNESS: 70-95 Shore A

Color：Original,Red, Yellow, Green, Black, Brown,and other color.

POLYURETHANE SHEET

(Thickness x Width x Length)

1mm

1000*4000

8mm

1000*4000

2mm

1000*4000

10mm

1000*4000

3mm

1000*4000

12mm

1000*4000

4mm

1000*4000

15mm

1000*4000

5mm

1000*4000

20mm

1000*4000

6mm

1000*4000

-

-

1mm

1200*4000

8mm

1200*4000

2mm

1200*4000

10mm

1200*4000

3mm

1200*4000

12mm

1200*4000

4mm

1200*4000

15mm

1200*4000

5mm

1200*4000

20mm

1200*4000

6mm

1200*4000

-

-

1mm

1280*4000

8mm

1280*4000

2mm

1280*4000

10mm

1280*4000

3mm

1280*4000

12mm

1280*4000

4mm

1280*4000

15mm

1280*4000

5mm

1280*4000

20mm

1280*4000

6mm

1280*4000

-

-

PU square plate

(Thickness x Width x Length)

10mm

500*500

55mm

500*500

15mm

500*500

60mm

500*500

20mm

500*500

65mm

500*500

25mm

500*500

70mm

500*500

30mm

500*500

75mm

500*500

35mm

500*500

80mm

500*500

40mm

500*500

90mm

500*500

45mm

500*500

100mm

500*500

50mm

500*500

-

-


Polyurethane encapsulation rubber, Polyurethane Roller.

Over the years, we have always been committed to the research and development of Conveyor Rubber Sealing System/Conveyor Skirt Board/ Skirting Sheets, continuously improving and innovating the products to meet customers' needs. In the process of development, we always adhere to the new development concept that green mountains are golden mountains. We have established a long-term, close and stable cooperative relationship with our customers.
